3DO PA12 CF 0.8KG - Black Carbon Fiber

3DO PA12-CF is a carbon fiber-reinforced polyamide filament designed for industrial applications requiring maximum strength, stiffness, and dimensional stability. With excellent thermal resistance and low warping tendencies, it is ideal for weight-critical projects such as aerospace and motorsport.
A hardened nozzle is recommended due to the abrasive nature of the carbon fibers.

  • Extremely high strength and stiffness
  • High thermal resistance with a Vicat softening temperature of 145°C
  • Lightweight, carbon fiber-reinforced for weight-critical projects
  • Requires a hardened nozzle due to abrasive carbon fibers
  • Nozzle: 260-290°C
  • Heatbed: 110°C
Colour
  • Black
Out-of-Stock
kr695.00
Tax included

Notify me when in stock

Drop your email and we'll let you know the moment it's back.



Technical Specifications

Property Test Method Unit Value
Density ISO 1183 g/cm³ 1.03
Melt Volume Rate (MVR) 235°C/5.0 kg ISO 1133 cm³/10min 7
Water Absorption (Saturation 23°C) ISO 62 % 1.6
Tensile Modulus ISO 527-1 MPa 2820
Tensile Strength ISO 527-2 MPa 60.4
Tensile Elongation ISO 527-2 % 4
Nominal Elongation at Break ISO 527-2 % >35
Charpy Notched Impact Strength (+23°C) ISO 179/1eA kJ/m² 9
Charpy Notched Impact Strength (-30°C) ISO 179/1eA kJ/m² 5
Charpy Unnotched Impact Strength (+23°C) ISO 179/1eU - No Break (NB)
Charpy Unnotched Impact Strength (-30°C) ISO 179/1eU - No Break (NB)
Puncture Maximum Force (-30°C) ISO 6603-2 J 62
Multiaxial Instrumented Impact Test, Peak Force -30°C ISO 6603-2 N 5400
Heat Deflection Temperature (DTUL) 0.45 MPa, unannealed ISO 75-2/B °C 139
Heat Deflection Temperature (DTUL) 1.8 MPa, unannealed ISO 75-2/A °C 58
Vicat Softening Temperature ISO 306/B50 °C 145
Mass Temperature ISO 11357-3 °C 185
CLTE Flow ISO 11359-2 μm/m°C 10
Specific Surface Resistance IEC 60093 ohms 100 trillion (1 × 1014)
Specific Volume Resistivity IEC 60093 ohms cm 100 trillion (1 × 1014)
Dielectric Strength IEC 60243-1 kV/mm 25
Comparative Tracking Index (CTI) IEC 60112 V 500
Type
PA12
Filament Diameter
1.75mm
