3DO PC-PBT is a versatile filament that blends the strengths of polycarbonate (PC) and polybutylene terephthalate (PBT).
It offers excellent mechanical properties, high thermal resistance, and outstanding chemical resistance, making it ideal for demanding industrial applications.
The material maintains good toughness even at low temperatures, ensuring reliable performance in harsh environments.
3DO PC-PBT is a high-performance filament that blends polycarbonate (PC) and polybutylene terephthalate (PBT), combining the strengths of both materials. This versatile filament offers exceptional mechanical properties, outstanding heat resistance, and excellent chemical resistance, making it ideal for demanding industrial applications. With the ability to maintain toughness even at low temperatures, 3DO PC-PBT is perfect for parts exposed to harsh environments. It is easy to print and delivers consistent, reliable results.
| Property | Test Method | Unit | Value |
|---|---|---|---|
| Density | ISO 1183 | kg/m³ | 1200 |
| Melt Volume-Flow Rate (MVR) | ISO 1133 | cm³/10 min | 18 |
| Tensile Modulus | ISO 527-1,-2 | MPa | 2200 |
| Yield Strength | ISO 527-1,-2 | MPa | 60 |
| Yield Strain | ISO 527-1,-2 | % | 5 |
| Nominal Elongation at Break | ISO 527-1,-2 | % | >50 |
| Flexural Modulus | ISO 178 | MPa | 2150 |
| Flexural Strength | ISO 178 | MPa | 80 |
| Charpy Notched Impact Strength | ISO 179/1eA | kJ/m² | 60 |
| Puncture Performance - Maximum Force | ISO 6603-2 | N | 3800 |
| Puncture Energy | ISO 6603-2 | J | 47 |
| Vicat Softening Temperature | ISO 306 | °C | 126 |
| Heat Deflection Temperature (1.8 MPa) | ISO 75-1,-2 | °C | 85 |
| Heat Deflection Temperature (0.45 MPa) | ISO 75-1,-2 | °C | 110 |
| Flammability UL 94 (1.5 mm) | UL 94 | Class | HB |
Store 3DO PC-PBT in a dry room at room temperature (18-27°C / 65-80°F), away from direct heat and sunlight. Proper storage ensures the material retains its quality for up to 2 years.
3DO PC-PBT is compliant with relevant industry standards, ensuring safety and reliability in various applications. For more detailed information, please refer to the technical data sheet.
