3DO ASA GF Makita Blue 1KG - UV-Resistant Industrial Filament
3DO ASA GF Makita Blue 1KG - UV-Resistant Industrial Filament
3DO ASA GF Makita Blue 1KG - UV-Resistant Industrial Filament
3DO ASA GF Makita Blue 1KG - UV-Resistant Industrial Filament

3DO ASA GF Makita Blue 1KG - Glass Fiber

3DO ASA-GF is a glass fiber-reinforced, UV-resistant, and weatherproof copolymer designed for high-performance industrial applications.
It offers exceptional rigidity, heat resistance, and low warping, making it ideal for mechanically stressed components exposed to outdoor conditions.
A hardened nozzle is recommended due to the abrasive nature of the glass fibers.

  • Glass fiber reinforcement for increased strength and stiffness
  • UV and weather-resistant, perfect for outdoor applications
  • High heat resistance and low distortion
  • Requires a hardened nozzle due to abrasive glass fibers
  • Compliant with REACH and RoHS regulations
  • Manufactured in EU
  • Nozzle: 230-270°C
  • Heatbed: 110°C
Colour
  • Makita Blue
In stock
kr303.20



3DO ASA-GF is a high-performance, glass fiber-reinforced ASA filament designed for industrial applications that demand superior mechanical properties and environmental resistance. This filament is specifically engineered to withstand UV exposure and harsh weather conditions, making it ideal for outdoor and automotive applications. The glass fiber reinforcement provides exceptional rigidity and heat resistance, while the material's low warping tendencies ensure reliable and precise printing results. Given the abrasive nature of glass fibers, it is recommended to use a hardened nozzle to prevent excessive wear on standard nozzles.

Key Features

  • Glass fiber reinforcement for increased strength and stiffness
  • UV and weather-resistant, perfect for outdoor applications
  • Matte surface finish for a professional and durable appearance
  • High heat resistance and low distortion
  • Low warping tendencies for reliable prints
  • Compliant with REACH and RoHS regulations
  • Requires a hardened nozzle due to abrasive glass fibers

Technical Specifications

Property Test Method Unit Value
Flexural modulus (E-Modulus) ASTM D790 MPa 3500 ±200
Tensile modulus (E-Modulus) ASTM D638 MPa 3520 ±200
Tensile strength ASTM D638 MPa 59.8 ±3
Flexural strength ASTM D638 MPa 91.2 ±3
Elongation at yield ASTM D638 % 3%
Nominal elongation at break ASTM D638 % 8% -0.02
Notched impact strength ASTM D256 kJ/m² 88
Unnotched impact strength ASTM D256 kJ/m² 16
Vicat Softening Temperature (VST/A) ASTM D1525 °C 101
Melting Temperature ISO 3146-C °C 190-210
Melt Flow Rate (MFR) ASTM D1238 g/cm³ 12
Heat Deflection Temperature (HDT/B) ASTM D648 °C 99
Shrinkage ASTM D955 % 0.30%
Density ASTM D792 g/cm³ 1.1
Hardness (Rockwell) ASTM D785 R-Scale 110
Flammability UL94 Class HB 1.5 mm

Storage and Shelf Life

Store 3DO ASA-GF in a dry room at room temperature (18-27°C / 65-80°F), away from direct heat and sunlight. Proper storage ensures the material retains its quality for up to 2 years.

Compliance and Additional Information

3DO ASA-GF is compliant with REACH and RoHS regulations, ensuring safety and environmental responsibility. For more detailed information, please refer to the technical data sheet.

Type
ASA
Filament Diameter
1.75mm
