3DO ASA CF 1KG - High-Performance Carbon Fiber Filament
3DO ASA CF 1KG - High-Performance Carbon Fiber Filament
3DO ASA CF 1KG - High-Performance Carbon Fiber Filament
3DO ASA CF 1KG - High-Performance Carbon Fiber Filament

3DO ASA CF 1KG - Carbon Fiber

3DO ASA CF is a carbon fiber-reinforced, UV-resistant, and weatherproof copolymer designed for high-performance industrial applications.
It offers exceptional rigidity, thermal stability, and low warping, making it ideal for mechanically stressed components exposed to outdoor conditions.
A hardened nozzle is recommended due to the abrasive nature of the carbon fibers.

  • Carbon fiber reinforcement for increased strength and rigidity
  • UV and weather-resistant, perfect for outdoor applications
  • High heat distortion resistance and thermal stability
  • Requires a hardened nozzle due to abrasive carbon fibers
  • Compliant with REACH and RoHS regulations
  • Manufactured in EU
  • Nozzle: 240-260°C
  • Heatbed: 110°C
Colour
  • Carbon Black
In stock
kr303.20



3DO ASA CF is a high-performance carbon fiber-reinforced ASA filament, engineered for industrial applications that require superior mechanical properties and environmental resistance. This filament is UV-resistant, weatherproof, and features a matte surface finish, making it ideal for outdoor use and mechanically stressed components. The carbon fiber reinforcement provides increased rigidity and heat distortion resistance, while the material's low warping tendencies ensure reliable and precise printing results. Due to the abrasive nature of carbon fibers, the use of a hardened, abrasive-resistant nozzle is required to prevent excessive wear on standard nozzles.

Key Features

  • Carbon fiber reinforcement for increased strength and rigidity
  • UV and weather-resistant, perfect for outdoor applications
  • Matte surface finish for a sleek, professional look
  • High heat distortion resistance and thermal stability
  • Low warping tendencies for precise prints
  • Compliant with REACH and RoHS regulations
  • Requires a hardened nozzle due to abrasive carbon fibers

Technical Specifications

Property Test Method Unit Value
Flexural Modulus (E-Modulus) ASTM D790 MPa 4500
Flexural Strength ASTM D790 MPa 78
Tensile Modulus (E-Modulus) ASTM D638 MPa 2500
Tensile Strength ASTM D638 MPa 49
Notched Impact Strength ASTM D256 kJ/m² 100 @ 23°C
Unnotched Impact Strength ASTM D256 kJ/m² 20 @ -30°C
Vicat Softening Temperature (VST/A) ASTM D1525 °C 101*
Melting Temperature ISO 3146-C °C 210-250
Melt Flow Rate (MFR) ASTM D1238 g/cm³ 9
Heat Deflection Temperature (HDT/B) ASTM D648 °C 96
Shrinkage ASTM D955 % 0.3
Density ASTM D792 g/cm³ 1.14
Hardness (Rockwell) ASTM D785 R-Scale 105
Flammability UL94 Class HB 1.5 mm
Carbon Fiber Content ASTM D785 %vol 12

Storage and Shelf Life

Store 3DO ASA CF in a dry room at room temperature (18-27°C / 65-80°F), away from direct heat and sunlight. Proper storage ensures the material retains its quality for up to 2 years.

Compliance and Additional Information

3DO ASA CF is compliant with REACH and RoHS regulations, ensuring safety and environmental responsibility. For more detailed information, please refer to the technical data sheet.

Type
ASA
Filament Diameter
1.75mm
52979
